Name: 5mm Pixel Pitch indoor Full Color Led Screen Smd3528 1/16 Scan Fixed Intallation
Brand: HJY

Dustproof Indoor Full Color LED Display , P3 LED Video Wall On Rent 120° Viewing Angle factory

Product Details:

Place of Origin:

China

Brand Name:

HJY

Certification:

CE FCC

Model Number:

Payment & Shipping Terms:

Minimum Order Quantity:

negotiable

Packaging Details:

flight case

Delivery Time:

15-20 days after receiving deposit

Payment Terms:

T/T, Western Union, MoneyGram

Supply Ability:

1000sqm per month

Product Description

P3 indoor rental led display full color rental stage led display indoor

Module Parameter:

Pixel pitch	3mm
Pixel Density	27,777 dots/m²
Pixel configuration	1R1G1B
LED type	3-in-1 black SMD2121
Module size	192*192mm
Module weight	298g
Module resolution	64*64dots
Module quantity	27.13 pcs/m²
Min. Viewing Distance	≥3m
Brightness	≥1200 cd/m²
Viewing Angle	H≤120° V≤120°
Driving Mode	1/32 scan constant current driving
Interface	HUB75
Input voltage	4.8-5.5VDC
Max. Power Consumption	1200 w/m²
Avg. Power Consumption	600 w/m²
Max. Current	7-7.5A
Frame rate	60 frames/s
Refresh Rate	≥3840Hz
Defective Dots Rate	<0.0001 (LED display line standard: ≤ 0.0003)
Decay Rate	≤5%/year
Brightness Conformity	>95%
MTBF	≥10000 hours
Lifespan	≥50000 hours
Protective function	Over-heat/Over-load /Power-down /Power-leakage/Lightning -protection etc.
Operating Temperature	-20℃~+50℃
Operating Humidity	10-85% no condensation
Storage Temperature	-30℃~+60℃
Storage Humidity	10-95% no condensation

Control System Parameter

Color temperature	Adjustable by software
Brightness control	256 levels, automatic adjustment.
Control way	Computer, real-time, off-line, wireless, network etc.
Communication Distance	Cat5 UTP 100 meters, max. 130 meters; or optical fiber.

* Die-casting aluminum, secure and nice in constitution.

* No fans, mute when operation.

* Dustproof, IP43.

* High refresh rate and high gray depth.

* Completely black LED with high contrast.

* Standard cabinet size is 576*576mm.

* Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the image won't be out of shape and color cast between the rang.

* Exactly connected and easy to install and dismount.
