Indoor HD Full Color LED Screen P2.5 IP43 Large Viewing Angle Long Lifespan factory

Product Details:
Place of Origin: China
Brand Name: HJY
Certification: CE FCC
Model Number: P2.5
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Packaging Details: wooden case or flight case
Delivery Time: 15-20days after receiving deposit
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 3000sqm per month

Detail Information

Detail Information

LED Chip: Kinglight IC Driver: MBI5124 Power Supply: Meanwell/G-energy LED Type: SMD1010 Input Voltage: 220/110V Life Time: 100000hours

Product Description

Product Description



Long lifespan Indoor HD Full Color LED Display P2.5 promotion led screen



Function

1. Excellent visual effect, better viewing effect for text and graphic or video



2. Large viewing angle,both H/V can reach 110 degree;getting vivid effect within any position of the viewing range;



3. High contrast ratio and good evenness, high uniformity,without mosaic



4. Resist of the high temperature and antioxidation and anti-statiic;



5. Any led in each pixel can be respectively replaced, which reduce the cost of the display maintaince.



6. Long using life & MTBF



type

SMD2121

composition

1R1G1B

Scan method

16S

resolution

64 x 64dots (W x H)

Pixel pitch

2.5mm

Leasing LED video screen Module size

160 x160 mm

Module quantity

3x3

resolution

192 x192(W x H)

Cabinet size

480 x480mm

Waterproof grade

IP43

Supply voltage

AC 220/110 ± 10 %,47~63Hz

Panel Type and Material

Die-casting aluminum

Best viewing distance

10-55m

Maximum power

1500W /m2

Viewing angle

140°/120°

Brightness

2000cd/m2

Pixel density

62052dot/m2

Control system

Synchronous/Asynchronization System

working temperature

-20º C to +50º C

Working humidity

20 % to 90 %

lifespan

100,000 hours

Frame frequency

60Hz

installation

Hanging/Fixed with support bracket

certification

CE, ROSH



Application



1. The applications for Multi Line Displays are endless.

2. Multi Line LED Electronic Displays are easy to use and can be up-dated quickly and with no technical expertise

3. Available in a variety of character heights: although if you have a multi line display made up from a number of Bi-Line displays, you can show a single line of text in double height format which will usually double these heights. Larger height signs are also available.

4. LED Colour Options are: RED, Green Blue, Yellow, Amber, Purple, Bi-color, RGB/Full Color.

5. Various speed and Characters: The signs can display most different Characters and Graphic Symbols.

6. The signs can run at variable Speeds, and have various display features including Bold, Run Left/Right etc."

7. Can be controlled remotely , like WIFI, GSM, GPRS,3G,4G,5G
