Quality Stage Rental LED Display & Outdoor Rental LED Display Manufacturer

P8 outdoor full color led display advertising led display billboard factory

Product Details:
Place of Origin: China
Brand Name: HJY
Certification: CE FCC
Model Number: P8
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Packaging Details: Wooden case
Delivery Time: 15-20 days after receiving deposit
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000sqm/month

Detail Information

Detail Information

Pixel Pitch: 8mm Pixel Configuration: SMD 3535 Module Size: 256mmx128mm Module Resolution: 32x16 Pixels Protection Grade: IP65 Operating Environment Temperature: -20°C—65°C Optional

Product Description

Product Description

P8 outdoor full color led display advertising led display billboard



Item Technical Specification
Pixel Pixel pitch:  8mm
Pixel configuration: 1R1G1B 3535
Brightness: Red: 600mcd Green: 2300mcd Blue: 500mcd
Wave length:  Red: 625±2nm  Green: 525±2nm  Blue: 470±2nm
Module Module size: 256mmx128mm
Module resolution:32x16 pixels
Cabinet Cabinet resolution: 1024*1024 pixels
Cabinet material: Steel
Gross weight: 45kg
Module quantity: 32pcs= 8(w) x 4(h)
Cabinet size: 1024mm×1024mm×150mm
Power consumption : Max.:800W/m² Average: 350W/m²
Screen parameter Drive method: 1/4 scanning
Brightness: 6000cd/m²
IC driver: MBI 5124
Density: 15625pixel/m²
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 16m
Viewing angle:  Horizontal: 120° Vertical:  60°
Humidity(RH): ≤ 90~95%
Working temperature: from -20°C~ +50°C
Working voltage: AC220V/110V±20%
Refresh frequency: ≥ 300Hz(Linsn)
Frame rate: ≥ 540Hz
Protection grade: IP65
MTBF: More than 10000hrs
Life time: 100,000 hrs
Control system Control system: Linsn/novastar
Signal interface: DVI
Communication distance: The shielded twisted-pair cable transmission distance for 100 meters, the biggest up to 140 m. Multimode fiber of up to 500 meters, the single-mode optical fiber to 20 kilometers
Systems operating platforms :XP,WINDOWS(WIN95,WIN98,WIN2000)
Input Signal:RF,S-VIDEO,RGBTV,YUT,YC,COMPOSITION
Image adjustment:contrast, tonal, the color saturation, gray calibration coefficient, color range, image variable times, etc
Life span:100,000 hours
Out-of Control rate:0.0001
Control system:Synchronized
Operating Environment Temperature :-20°C—65°C Optional



P8 outdoor full color led display advertising led display billboardP8 outdoor full color led display advertising led display billboard

1. Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
2.  High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.
3.  First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system
4.  Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment
5.  Long-term Brightness:
 Automatic or manual adjustment of the brightness of the display.
6.  Easy Installation & Using:
easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
7.  Convenient Servicing:

Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion
