Name: 5mm Pixel Pitch indoor Full Color Led Screen Smd3528 1/16 Scan Fixed Intallation
Brand: HJY

Product Description

P2 indoor hd led video wall small and clear video led module screens

Unit Module	Item:	LED Parameter
	Model:	P2
	Pixel Pitch:	2mm
	Pixel configuration:	1R1G1B 3in1 SMD
	Module Size:	128mm * 128mm
	Module Resolution:	64dots(W) * 64dots(H)
	Module Thickness:	14.75 mm
	Module Weight:	0.12 KG
	LED type:	SMD1010
	Max Power:	16W
	Pixel Density:	250000 dots / SQM
	Driving Method:	Constant Current Driving
	Scan Method:	1/32 Scan
	Interface Way:	HUB 75
	Brightness:	≥ 1000CD /SQM
Unit Cabinet	Cabinet Size:	512mm * 512mm (Support Customize)
	Cabinet Composing:	16 pcs
	Power Supply Mode:	5V/40A 5V/60A
	Cabinet Resolution:	256dots * 256dots
	Optimal Viewing Distance:	2-30M (according to the screen size)
	Optimal Viewing Angle:	Horizontal angle: 160 degree; Vertical angle: 90 degree
	Environment Temperature:	Storage: -40 degree `~ +85 degree Work: -20 degree ~ +60 degree
	Relative Humidity:	10% ~ 95%
Power	Operating Voltage:	AC:100V~120V AC:220~240V
	Average Power:	100W/ SQM
	Max Power Consumption:	≤ 620W
	Current:	≤ 20mA (single LED)
Control System	Computer:	Pentium4 or above P4 or above
	Operate System:	Win98/2000/NT/XP/7/8
	Control Mode:	Synchronization with PC
Main Technical Parameter	Driving Device:	IC Constant Current Driving (RGX)
	Refresh Rate:	≥ 1920Hz
	Gray/Color:	RGB each 256 grade, can display 16.7color
	MTPF:	≥ 9000hours
	Power Switch:	Automatic Switch (RGX)
	Display Mode:	80060010247681280*960

Our Advantage:

1) Competitive price with high quality

2) Professional manufacturer

3) Exquisite quality

a: CE FCC certification

b: Each procedure have special machine and QC to supervise and check

c: From the material purchasing, all have the special Equiment to stakeout

4) Perfect service

a; 2years guarantee

b: Free training in our company or on lone training by long-distance control in internet

c: provide strong technology for each customer at the first time

5) Delivery date is quick and on time

6) New product exploring

Small Size LED Panel Screen Indoor 2mm Pixels Clear Video LED Module Screens

Tag:

Product Details:
Place of Origin:	China
Brand Name:	HJY
Certification:	CE FCC
Model Number:	P2
Payment & Shipping Terms:
Minimum Order Quantity:	negotiable
Packaging Details:	Wooden case
Delivery Time:	15-20 days after receiving deposit
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	1000sqm per month
